The PTS40 temperature sensor was specifically designed for temperature applications in the automotive aftermarket and industrial markets. The part is fit, form, and function the same as the Delphi TS10075, and AC Delco 213-928. The brass tube encapsulated NTC allows for protection against water ingress that cause traditional temperature sensors to fail. The simple design can be modified to meet our OEM customers challenging applications. The low cost semi-automated manufacturing process allows for a cost effective solution.

PTS40

PTS40 Specifications

  • Delphi TS10075 Engine Coolant Temperature Sensor
  • AC Delco 213-928 GM _ Temperature Sensor
  • -40-125°C Operating Temperature
  • +- 1% @ 25C
  • NTC Polyimide Sheath probe
  • Beta 3977 NTC (Other Options available
  • IP65
  • Quick Disconnect
  • Media – Liquid, Air, & Gas

PTS 40 Applications

  • Process Control
  • Automotive
  • Engine Coolant, Oil
  • SPAS
  • HVAC
