Phoenix Sensors is a US manufacturer of pressure sensors like the WEPS02 series. The WEPS02 is a Bluetooth wireless pressure sensor manufactured for simple measurements on a variety of applications. This silicon pressure sensor was designed to supply an economical solution for industrial, consumer, and commercial applications.
Simply download the Phoenix Sensors application from our website and connect to the device. The sensor will wake-up with any kind of vibration and will shut down automatically when it is not in use to preserve the battery. The battery version will last up 2 years in continuous (1 measurement/10 sec) use. Please contact us for Custom design availability.
The Mobile Software enables the user to store data to evaluate later. The sensor’s on-board memory stores up to 200 hours of data for troubleshooting or evaluation of system pressure or temperature.
Wireless Pressure Sensor WEPS02 Specifications
- Wide Pressure Range (1PSI-5kPSI)
- -20-85°C Operating Temperature
- Compact Size
- Total Error Band 1%
- BLE Wireless Communication (IOS)
- 1-5000 psi pressure ranges
- Absolute, Vacuum
- Media – Liquid, Air, & Gas
- IP65 (& IP67)
- Auto Shut-Off (Sleep Mode)
- Consumer products
- Industrial Automation
- Pool Pumps
The two piece body design is made of SS316, which allows for easy low-cost manufacturability and corrosion resistance. Vibration proof design for use in industrial applications. Plastic option is available for custom designs
The silicon MEMS pressure sensor element is mounted to a ceramic base and sealed into the SS316 (or Brass) housing. The selection of thermally capability materials reduce the mechanical stress on the sensor resulting in greater stability over time and temperature.
Additional stability is gained from factory stabilization of all sensors.
1/4” -18NPT and 1/8”-18NPT threads are standard SS fittings. Other port fittings such as 7/16-20UNF, and ¼” BSP are available for OEM customers.
The pressure port is tolerant to most media including but not limited to oil, air, gas, and non-corrosive media. Sensor will only work on a temporary basis in any non-air application. Sensor will need to have a period of time to dehydrate.
When checking media capability, the wetted surface is composed of Aluminum and Silicon Gel.
Standard pressure ranges are 15, 30, 50, 100, 150, 300, 1k, 3k, and 5k psi in absolute and gage. Custom pressure ranges are available for OEM customers.
